Product Description

SPECIFICATIONS:
Size: 2"to 8"
Capacity: 18-620 m3/h
Head: 5-28 m
Efficiency: up to 55%
Materials: Hyper chrome alloy, Rubber, Polyurethane, Ceramic, Stainless steel etc.

AIER® WP Vertical Froth Pump

WP Series of Froth Pumps is efficiency pump product which is manufactured by Aier Machinery Hebei Co., Ltd under the advanced manufacture technology introduced from one famous Australian company.

 Typical Applications

WP vertical froth pumps are suitable for handling solids-liquid mixture, special for delivering frothy pulp generated in flotation machines in metaliferoous and coal flotation circuits.

 Features

The basic principle of the pump is much higher than that of other types of slurry pump without shaft seal and sealing water. The froth pump is a perfect pump for handling frothy pulp indeed.

The Construction of pump head is double casing which is similar with standard construction of Warman slurry pump. All wet-parts can be supplied in Ni-hard, high chrome alloy iron and pressure-moulded natural or synthetic rubber. The drive end can be exchanged with that of type WY (equivalent to Warman SP) & WYJ (equivalent to Warman SPR) pumps. The hopper-tank is fabricated with steel plate.  Its inner wall of the tank can be covered with liner according to different medium pumped. The discharge branch can be positioned at intervals of 45 degrees by request and oriented to any eight positions to suit installations and applications.

The advantages of the pump are of excellent performance, easy assembly & disassembly, high reliability, and etc.

 Type Notation

Example：50WP-Q

                  50 - Discharge Diameter（mm)

                   Q - Frame Type

                   WP - Froth Pump
